Understanding Practical Shotgun: Ammunition by Brian Nelson
When it comes time to buy ammunition for a 3-Gun or Practical Shotgun match, the process can be a little bit confusing. Spending time around a lot of 3-Gunners, it’s clear that even experienced action shooters sometimes don’t understand what all that stuff on the box means.
First, the basic types of shotgun shells: Birdshot, Buckshot and Slugs. In Practical Shotgun matches, you’ll primarily be using birdshot. Most US 3-Gun/PSG matches require a few slugs in different formats, while buckshot is infrequently required in the US (but generally accounts for 1-2 courses in the average overseas IPSC match).
Legality: While in the US there isn’t a single unified rulebook for 3-Gun/PSG matches, the general requirements are all pretty much the same:
- Size: Generally shot sizes for birdshot may not be larger than #6
- Material: Generally only lead shot is allowed (steel/tungsten shot is prohibited to prevent ricochet/target damage on steel plates).
- Plating: The United Multigun League and some unaffiliated matches prohibit shot with any type of plating (copper/nickel). Plated shot is generally only found in expensive hunting loads that are hard-recoiling and not desirable for PSG.
- Wad Type: IPSC matches (and some outlaw matches that crib off IPSC rules) prohibit “specialized long-range wads”. Most US matches are ambivalent about wads, and they are generally only found in hard-recoiling hunting loads which are not desirable for PSG.
- Power Factor: In IPSC, there is a minimum “Power Factor” of 480. Power factor is measured as: Weight in Grains, multiplied by velocity, divided by 1000. For example, a 1 1/8oz load traveling at 1145fps is 514*1145/1000=588PF. Most US matches do not have a minimum power factor.
- Reliability: It doesn’t matter if you’re using a mag-fed auto or a tube-fed pump shotgun, the biggest contributor to reliability is the ammunition you put in the shotgun. Poorly made shells will have problems feeding into the chamber from the magazine as well as being extracted and ejected from the shotgun. It’s also very easy to accidentally buy ammunition that’s high quality, but not designed to reliably function your semi-auto shotgun.
- Power: Here is a main difference between US outlaw matches and IPSC: IPSC has a minimum power factor of 480 (shot weight in grains*velocity/1000=PF), but has a calibration standard for falling targets that can be appealed to contest a miss penalty. Most US matches don’t care what your ammo power factor is, but if you can’t knock over a target, that’s your problem.
- Recoil: In general, less recoil is desirable. Not just from a comfort perspective, it’s about speed – the less the shotgun moves, the quicker it can return to the target, hence the faster targets can be neutralized.
- Pattern uniformity: A huge part of speed shotgunning is utilizing the expanding pattern of a shotgun to allow us to aim less. If a pattern at a given distance is 10” consistently, that means that the shooter simply needs to put the bead within a 9” radius of the target, meaning that shots can be made without waiting for a perfect sight alignment. If the birdshot pattern is 10” on one shot, 12” on another, then 6” on another, to guarantee a hit the shooter must basically place the bead exactly on the target. In the case of no-shoot targets placed near a shoot target, with a consistent pattern the shooter can use a more open choke to enable speedy shooting on open targets while using the edge of the pattern to neutralize “danger” targets. With an inconsistent pattern, constricting the pattern with a tight choke is the only way to guarantee a penalty-free stage, but that comes at the penalty of speed on open targets.
- Steel in Base: Several types of shell carrier (such as the author’s King Competition carriers) use magnets to retain shells. For those using these carriers, seek out a shell with a plated steel base of some kind.
What makes a reliable shell?
Base: The metal base makes the rim that the extractor grips. On cheap shells, the base is poorly bonded to the plastic hull and will often be pulled off and extracted from the firearm, leaving the hull stuck in the chamber. Poor bases will also expand and stick in the chamber, causing extraction problems even in manual shotguns.
Hull: Flimsy plastic hulls deform easily from impact or even from heat. This can cause significant feeding problems. Stiff hulls found in match-grade target shells are far less susceptible to deformation. Magazine-fed shotguns are particularly sensitive to hull deformation as the shell has a much less direct path into the chamber.
Crimp: The crimp holds the shot into the shell itself, and forms the end of the shell. A poor crimp can cause a hangup on the edge of the chamber during feeding. This problem is present in all shotguns but is magnified in magazine-fed shotguns which are hypersensitive to any feeding imperfections.
Properly Powered: Whether they be inertia-driven or gas-operated, all semi-auto shotguns need some sort of power to cycle. The power of the shell determines the speed of the bolt cycling, so excessively-powered shells can also cause malfunctions and accelerate wear on parts.
Shell Terminology Explained:
On any given box of shells, you’ll find all the information you’ll need to figure out if they’ll cycle your shotgun.
Length: 12 Gauge shells are available in various lengths to fit more powder and/or shot. For practical shotgun purposes, 99.9% of the time a 2 ¾” shell is desired.
Shot Size: This is the size of an individual pellet – which will determine how much energy is delivered on target by a single pellet, but has nothing the function of the shotgun*. The smaller the shot, the wider and denser the pattern of the shotgun becomes, at the cost of energy on target. Target shells are typically available in #7 ½, #8 and #9 shot.
Shot Weight: In the US, target shells are typically 7/8oz, 1oz, or 1 1/8oz. More weight means more pellets of shot, which means a wider pattern. Shot weight, combined with velocity, will determine the function of your shotgun.
Velocity: Bear in mind, this is only the manufacturer’s stated velocity, but it will give you an idea of whether the firearm will cycle with the ammo or not. IPSC measures with a chronograph, so if power factor is a concern then select a factory load that should give you a comfortable margin and if possible test over a chronograph.
Dram Equivalent: This is a holdover from the turn-of-the-century transition from black to smokeless powder. Commercial ammunition was labeled by powder charge in drams. When smokeless shells came around, manufacturers stated that the new ammunition was equivalent to the old dram system. The lowest-recoiling shotgun load that will reliably cycle a semi-auto would be “2 ¾ Dram”.
Regardless of manufacturer, most of them all offer some version of the same type of load. Here’s what it means when you see “handicap” or “light target” on the box:
- “Extra-Light Target” – Cycles Benelli Inertia autoloaders
1oz shot, 1180fps (2 ¾ dram)
- “Light Target” – Cycles Benelli Inertia autoloaders
1 1/8oz shot, 1145 fps (2 ¾ Dram)
- “Heavy Target” – Cycles modified/Broken-in Stoeger autoloaders
1 1/8oz shot, 1200 fps (3 Dram)
- “Light Handicap” – Cycles new Stoeger autoloaders, recommended for all box-fed autos
1oz shot, 1250-1290 fps (3 Dram or “HDCP” Dram)
Junk, Budget, Mid-Tier and Match Birdshot
I believe there are four tiers of birdshot.
Budget birdshot is the cheapest that’s commonly available. This ammunition is generally still reliable in tube-fed shotguns but you will see more bad rounds slip through as the manufacturer QC isn’t as tight. These shells don’t pattern very uniformly, but are still a reliable option for practice.
All budget birdshot is not created equal, however. Junk birdshot costs the same as good budget birdshot, but is made poorly. Inconsistent powder charges, bad crimps, flimsy hulls and poor bases are the main problems with junk birdshot.
In the US, Estate and the Federal Bulk Packs (available at Walmart) are good, reliable budget birdshot. Avoid ANY Winchester shell that isn’t a AA, as it’s likely junk (Universal is the worst shotgun shell available and Super Target/Win3Gun aren’t much better).
Mid-Tier birdshot offerings generally consist of a good wad and high-quality lead shot in an OK hull. These shells pattern well and are very reliable in a tube-fed shotgun, but a stiffer hull is usually desired for use in box-fed shotguns. Additionally, most of these shells are made with a steel base (sometimes plated with a different material), meaning they stick well to magnetic shell caddies (or hull pickers, for easy range cleanup).
Remington Gun Club and Federal Top Gun Target are both good examples of mid-tier birdshot.
Match-grade birdshot is the best ammunition available. Stiff hulls, good crimps, quality shot and wads as well as tight QC means this has the best chance of running reliably and patterning uniformly. Examples include Winchester AA, Remington STS and Federal Gold Medal Grand. Of note, most of these shells have an all-brass base, so they won’t stick to a magnet. Gold Medal Grand is the only match shell I’m aware of with any steel in the base, so it’s the author’s choice of match shell for his King Competition caddies.
Here is a link to chrono data for birdshot ammunition tested by Brian – CHRONO.pdf
